Model BW150 and W150 (without boards)

Model BW150 and W150 (without boards)
Model BW150 and W150 (without boards)Model BW150 and W150 (without boards)Model BW150 and W150 (without boards)Model BW150 and W150 (without boards)Model BW150 and W150 (without boards)Model BW150 and W150 (without boards)
Model BW150
Code Length mm Weight (compl.) kg Load for ramp set in kg with chassis base between axles in mm Width (inside) Width (outside)

Board height
1500 1750 2000
BW150/30 3000 90 7009 8411 8411 450 512 36
BW150/35 3500 101 5257 6008 7009 450 512 36
BW150/40 4000 117 4500 4970 5425 450 512 36
BW150/45 4500 128 3504 3823 4205 450 512 36
Model W150 (without boards)
Code Length mm Weight (compl.) kg Load for ramp set in kg with chassis base between axles in mm Width (inside) Width (outside)

Board height
1500 1750 2000
W150/30 3000 90 7009 8411 8411 450 512 there is no
W150/35 3500 101 5257 6008 7009 450 512
W150/40 4000 117 4500 4970 5425 450 512
W150/45 4500 128 3504 3823 4205 450 512
