Model B190 and 190 (without boards)

Model B190 and 190 (without boards)
Model B190 and 190 (without boards)Model B190 and 190 (without boards)Model B190 and 190 (without boards)Model B190 and 190 (without boards)Model B190 and 190 (without boards)Model B190 and 190 (without boards)
Model B190
Code Length mm Weight (compl.) kg Load for ramp set in kg with chassis base between axles in mm Width (inside) Width (outside)

Board height
1500 1750 2000
B190/35 3500 130 10650 10918 10918 500 562 36
B190/40 4000 150 8520 9467 10650 500 562 36
B190/45 4500 166 7100 7746 8520 500 562 36
Model190 (without boards)
Code Length mm Weight (compl.) kg Load for ramp set in kg with chassis base between axles in mm Width (inside) Width (outside)

Board height
1500 1750 2000
190/35 3500 130 10650 10918 10918 500 562 there is no
190/40 4000 150 8520 9467 10650 500 562
190/45 4500 166 7100 7746 8520 500 562
