Model B170 and 170 (without boards)

Model B170
Model B170
Code	Length mm	Weight (compl.) kg	Load for ramp set in kg with chassis base between axles in mm			Width (inside)	Width (outside)	Board height
Code	Length mm	Weight (compl.) kg	1500	1750	2000	Width (inside)	Width (outside)	Board height
B170/30	3000	105	10507	10738	10738	450	512	36
B170/35	3500	110	7880	9006	10507	450	512	36
B170/40	4000	130	6304	7004	7880	450	512	36
B170/45	4500	141	5253	5731	6304	450	512	36
Model 170 (without boards)
Model 170 (without boards)
Code	Length mm	Weight (compl.) kg	Load for ramp set in kg with chassis base between axles in mm			Width (inside)	Width (outside)	Board height
Code	Length mm	Weight (compl.) kg	1500	1750	2000	Width (inside)	Width (outside)	Board height
170/30	3000	105	10507	10738	10738	450	512	there is no
170/35	3500	110	7880	9006	10507	450	512	there is no
170/40	4000	130	6304	7004	7880	450	512	there is no
170/45	4500	141	5253	5731	6304	450	512	there is no
