Model B150 and 150 (without boards)

Model B150 and 150 (without boards)
Model B150 and 150 (without boards)Model B150 and 150 (without boards)Model B150 and 150 (without boards)Model B150 and 150 (without boards)Model B150 and 150 (without boards)Model B150 and 150 (without boards)
Model B150
Code Length mm Weight (compl.) kg Load for ramp set in kg with chassis base between axles in mm Width (inside) Width (outside)

Board height
1500 1750 2000
B150/30 3000 85 7009 8411 8411 400 462 36
B150/35 3500 95 5257 6008 7009 400 462 36
B150/40 4000 110 4500 4970 5425 400 462 36
B150/45 4500 120 3504 3823 4205 400 462 36
Model 150 (without boards)
Code Length mm Weight (compl.) kg Load for ramp set in kg with chassis base between axles in mm Width (inside) Width (outside)

Board height
1500 1750 2000
150/30 3000 85 7009 8411 8411 400 462 nėra
150/35 3500 95 5257 6008 7009 400 462
150/40 4000 110 4500 4970 5425 400 462
150/45 4500 120 3504 3823 4205 400 462
