Model B115 and 115 (without borads)

Model B115 and 115 (without borads)
Model B115 and 115 (without borads)Model B115 and 115 (without borads)Model B115 and 115 (without borads)Model B115 and 115 (without borads)Model B115 and 115 (without borads)Model B115 and 115 (without borads)
Model B115
Code Length mm Weight (compl.) kg Load for ramp set in kg with chassis base between axles in mm Width (inside) Width (outside)

Board height
1000 1250 1500
B115/30 3000 52 2800 3000 3500 300 350 36
B115/32 3200 55 2610 2800 3300 300 350 36
B115/35 3500 60 2295 2550 2868 300 350 36
B115/40 4000 66 1910 2080 2295 300 350 36
Model 115 (without borads)
Code Length mm Weight (compl.) kg Load for ramp set in kg with chassis base between axles in mm Width (inside) Width (outside)

Board height
1000 1250 1500
115/30 3000 52 2800 3000 3500 300 350 there is no
115/32 3200 55 2610 2800 3300 300 350
115/35 3500 60 2295 2550 2868 300 350
115/40 4000 66 1910 2080 2295 300 350
