Model 100 and 100B (without boards)

Model 100 and 100B (without boards)
Model 100 and 100B (without boards)Model 100 and 100B (without boards)Model 100 and 100B (without boards)Model 100 and 100B (without boards)Model 100 and 100B (without boards)Model 100 and 100B (without boards)
Model B100
Code Length mm Weight (compl.) kg Load for ramp set in kg with chassis base between axles in mm Width (inside) Width (outside)

Board height
1000 1250 1500
B100/25 2500 39 2150 2350 2600 300 350 30
B100/30 3000 44 1810 2020 2340 300 350 30
B100/35 3500 49 1500 1760 1950 300 350 30
Model100 (without board)
Code Length mm Weight (compl.) kg Load for ramp set in kg with chassis base between axles in mm Width (inside) Width (outside)

Board height
1000 1250 1500
100/25 2500 39 2150 2350 2600 300 350 there is no
100/30 3000 44 1810 2020 2340 300 350
100/35 3500 49 1500 1760 1950 300 350
Send inquiry
